2 sec residence manual load general waste incinerator 150kgs

Primary Combustion Chamber

Secondary Combustion Chamber

Mix-Combustion Chamber

Smoke Filter Chamber(Dry Scrubber)

Incinerator Control Case

Model	YD-300
Incinerator Burning Rate	Average 150 kgs/hour
Primary Combustion Chamber	2400 Liters
Secondary Combustion Chamber	1200 Liters
Mix Combustion Chamber	Yes
Smoke Filter Chamber	Yes
Incinerator Feed Mode	Manual
Incinerator Voltage	220V/380V
Fuel Type	Diesel Oil/ Natural Gas/LPG
Burner	Italy Original
Oil Consumption (Diesel Oil)	28 kg/hour
Gas Consumption (Natural Gas)	***
Internal Dimensions	220 x 110 x 100cm (primary chamber)
External Dimensions	260 x 220 x 420cm (without chimney)
Temperature Monitor	Yes
Oil Tank Capacity(if oil fuel)	500 Liters
Door Opening	90 x 110cm
Chimney Length	10.0 Meters
Chimney Type	Stainless Steel
Incinerator Gross Weight	8300 kgs
Operation Technical Specifications
Primary Chamber Temperature	800℃–1000℃
Secondary Chamber Temperature	1000℃-1200℃
Residency Time	2.0 Sec.
Burning Efficiency	＞98%
Waste Lower Calorific Power	3000Kcal
